Cameras |
imaging |
FLI PL-16803 camera with |
|||||||||||||
|
|
|
|
65mm shutter |
||||||||||||
|
|
|
|
Anti-Dew Technology |
||||||||||||
|
|
|
FLI Centerline filter wheel with: |
|||||||||||||
|
|
|
|
Astrodon
generation 2 LRGB E-series 50mm square filter set |
||||||||||||
|
|
|
|
(L includes UV, NIR blocking) |
||||||||||||
|
|
|
|
Astrodon
5mm Ha 50mm square filter |
||||||||||||
|
|
|
|
Astrodon
5nm OIII 50mm square filter |
||||||||||||
|
|
|
|
Astrodon 5nm SII 50mm square
filter |
||||||||||||
|
|
|
FLI Centerline to Proline flange |
|||||||||||||
|
|
|
Precise Parts AP 2.7” to Centerline adapter |
|||||||||||||
|
|
|
|
|||||||||||||
|
|
guiding |
SBIG ST-402ME camera
with |
|||||||||||||
|
|
|
|
internal filter wheel |
||||||||||||
|
|
|
|
T mount to 1 ¼” nosepiece |
||||||||||||
|
|
Astrodon MonsterMOAG off-axis guider (AP 2.7” on both
sides) |
||||||||||||||
|
|
|
1.0” x 1¼” extension tube |
|||||||||||||
|
|
|
|
|||||||||||||
|
|
solar |
Imaging Source DFK41AU02.AS color camera (with
IR filter) |
|||||||||||||
|
|
system |
ZWO ASI178MM Mono camera (without IR filter) |
|||||||||||||
|
|
|
Coronado SolarMax 60 Ha filter with T-Max
and BF10 (0.7Å) |
|||||||||||||
|
|
|
Daystar Quark Chromosphere Ha filter (0.3-0.6Å) |
|||||||||||||
|
|
|
C mount to 1¼” nosepiece |
|||||||||||||
|
|
|
|
|||||||||||||
|
|
all sky |
Starlight Xpress Oculus camera with 150° fish eye lens |
|||||||||||||
|
|
|
|
|||||||||||||
|
Scopes |
high |
Planewave 12.5” CDK
scope (12’5” aperture, 2541mm focal length,
f/8) with |
|||||||||||||
|
|
resolution |
|
delta T heater |
||||||||||||
|
|
|
|
Electronic Focus Adapter |
||||||||||||
|
|
|
|
piggyback dovetail |
||||||||||||
|
|
|
Alnitak (now Optec)
Flat-Man L light “box” |
|||||||||||||
|
|
|
Planewave AP 2.7” extension tube adapter |
|||||||||||||
|
|
|
AP 0.60”, 0.75”, 0.90”, 1.25”, 1.75”, 2.5” extension
tubes |
|||||||||||||
|
|
|
Optec 0.5” extension tube |
|||||||||||||
|
|
|
AP standard & short 2” nosepiece adapters |
|||||||||||||
|
|
|
|
|||||||||||||
|
|
wide |
Takahashi FSQ-106 EDX
III scope (106mm aperature,
530mm focal length, f/5) with |
|||||||||||||
|
|
field |
|
Takahashi focuser and CAA removed |
||||||||||||
|
|
|
Precise Parts FSQ to Takahashi Auxiliary Ring M92
adapter |
|||||||||||||
|
|
|
Precise Parts Takahashi Auxiliary Ring M92 to AP 2.7”
extension tube adapter |
|||||||||||||
|
|
|
FLI Atlas focuser |
|||||||||||||
|
|
|
|
|||||||||||||
|
Mount |
|
AP900 mount with
GTOCP3 microcontroller level V, firmware v4.19.2 |
|||||||||||||
|
|
|
AP DOVELM162 16” easy balance saddle plate (3 knob style) |
|||||||||||||
|
|
|
AP 900FSA flat surface adapter (fits on flat
surface of pier) |
|||||||||||||
|
|
|
AP 900RPA rotating pier adapter (fits between AP
900FSA and AP900) |
|||||||||||||
|
|
|
1 AP 24lb & 3 AP 18lb counter weights (with
Planewave scope) |
|||||||||||||
|
|
|
2 AP 18lb counter weights (with
FSQ-106 scope) |
|||||||||||||
|
|
|
La Sueur 4¼“ pier
(actually
have 2 piers for separate locations) |
|||||||||||||
|
|
|
|
|||||||||||||
|
Miscellaneous |
|
Intel NUC computer D54250WYK (i5
at 1.3 Ghz) for image capture with |
|||||||||||||
|
Hardware |
|
|
Crucial 8 GB DDR3 memory |
||||||||||||
|
|
|
|
Crucial M500 240 GB mSATA drive |
||||||||||||
|
|
|
|
4 USB 3.0 ports |
||||||||||||
|
|
|
|
|
1 TB flash drive
(U32 Shadow external USB 3.0 hard drive) |
|||||||||||
|
|
|
|
|
USB 2.0 hub |
|||||||||||
|
|
|
|
|
USB 3.0 hub |
|||||||||||
|
|
|
|
|
external port 1 |
|||||||||||
|
|
|
|
dual band 802.11 ac/a/b/g/n WiFi plus Bluetooth |
||||||||||||
|
|
|
|
10/100/1000 ethernet CompuLab Display Emulator |
||||||||||||
|
|
|
|
Cable Matters female HDMI to male mini HDMI adapter |
||||||||||||
|
|
|
Digital
Loggers Inc. Web Power Switch 7 with multiple power supplies |
|||||||||||||
|
|
|
|
port 1: ST-402 |
Celestron
18778 2.5 amp 12v |
|||||||||||
|
|
|
|
port 2: PL-16803 & Centerline |
PowerSolve
PSG120-12 10 amp 12v (from FLI) |
|||||||||||
|
|
|
|
port 3: AP900 |
Pyramid
PS138V5A 5 amp 13.8v (from AP) |
|||||||||||
|
|
|
|
port 4: Planewave EFA & heater |
Celestron
18780 5.0 amp 12v |
|||||||||||
|
|
|
|
port 5: computer |
19v supply |
|||||||||||
|
|
|
|
port 6: USB 2.0 hub |
Celestron
18778 2.5 amp 12v |
|||||||||||
|
|
|
|
port 7: Ethernet switch |
9v supply |
|||||||||||
|
|
|
|
port 8: unused |
|
|||||||||||
|
|
|
|
Power Switch, Sky Quality, Cloud Watcher controlled by
physical switch |
||||||||||||
|
|
|
TP-Link
TL-SF1005D 5 port 10/100 ethernet switch |
|||||||||||||
|
|
|
Power
Switch |
|||||||||||||
|
|
|
computer |
|||||||||||||
|
|
|
home
LAN |
|||||||||||||
|
|
|
2
unused ports |
|||||||||||||
|
|
|
Digi
301-1010-78 7 port USB 2.0 hub |
|||||||||||||
|
|
|
|
AP900 (through serial adapter) |
||||||||||||
|
|
|
|
Planewave
EFA (through serial adapter) |
||||||||||||
|
|
|
|
Planewave
heater |
||||||||||||
|
|
|
|
PL-16803,
Centerline (& Atlas when using FSQ106) |
||||||||||||
|
|
|
|
THUM
temperature probe |
||||||||||||
|
|
|
|
power
meter (monitors AP900) |
||||||||||||
|
|
|
|
ST-402 |
||||||||||||
|
|
|
Anker
SuperSpeed 10-port USB 3.0 hub |
|||||||||||||
|
|
|
|
external
port 2 |
||||||||||||
|
|
|
|
external
port 3 (sky quality
meter & cloud watcher) |
||||||||||||
|
|
|
|
8
unused ports |
||||||||||||
|
|
|
Keyspan
USA-19HS 1 port USB 2.0 to serial adapter (drives AP900) |
|||||||||||||
|
|
|
Digi-Key
768-1013-ND FTDI USB 2.0 to serial adapter (drives Cloud Watcher) |
|||||||||||||
|
|
|
Digitus
USB 2.0 to serial adapter supplied by Planewave (drives Planewave
EFA) |
|||||||||||||
|
|
|
West
Marine Radio PWRcheck |
monitor
AP900 power |
||||||||||||
|
|
|
Unihedron Sky Quality Meter |
measures sky ‘darkness’ |
||||||||||||
|
|
|
AAG
Cloud Watcher |
monitor clouds and rain |
||||||||||||
|
|
|
THUM |
monitor temperature & humidity |
||||||||||||
|
|
|
Hotech
Advanced CT Laser Collimator |
scope
collimation |
||||||||||||
|
|
|
TeleGizmos
365 series cover 170”x56” |
mount placed at park 1 position |
||||||||||||
|
|
|
|
|
||||||||||||
|
Primary |
|
64 bit
Windows 7 Home Premium |
used for image capture |
||||||||||||
|
Software |
|
64 bit
Windows 10 Home |
used for
image processing |
||||||||||||
|
|
ASCOM
6.4SP1 plus: |
||||||||||||||
|
|
|
|
AP900
ASCOM driver |
||||||||||||
|
|
|
|
APCC
Pro 1.7.1.1 |
AP900
pointing & tracking correction |
|||||||||||
|
|
|
MaxIm
DL Pro 6.20 plus plugin: |
|||||||||||||
|
|
|
|
PWI
Plate Solve 0.0.5 |
interface
to Planewave PlateSolve |
|||||||||||
|
|
|
|
CCDPlugFingerLakes 1.2.3.0 |
Interface
to FLI hardware |
|||||||||||
|
|
|
PinPoint 6.1c |
DC-3 Dreams plate solution |
||||||||||||
|
|
|
PlateSolve 2.28 |
|
Planewave plate solution |
|||||||||||
|
|
|
PWI
3.4.1 beta 2 |
control Planewave focus, fans, heater |
||||||||||||
|
|
|
TheSkyX 10.5.0.12304 plus
plugin: |
planetarium & control scope |
||||||||||||
|
|
|
|
X2AscomTelescope
1.0.2 |
interface to AP900 ASCOM driver |
|||||||||||
|
|
|
FocusMax 4.1.0.85 |
automate focus |
||||||||||||
|
|
|
CCDAutoPilot
5.10.1 |
automate overnight run |
||||||||||||
|
|
|
CCDStack 2.93 |
|
align/stack & build RGB image |
|||||||||||
|
|
|
eXcalibrator 5.00 |
color
balance |
||||||||||||
|
|
|
Photoshop
CS6 64 bit plus
plugins/actions: |
|||||||||||||
|
|
|
|
Eddie Trimarchi’s FITSPlug 2 |
read/write
fit format |
|||||||||||
|
|
|
|
Russell
Croman’s GradientXTerminator 1.2.0 |
remove
light gradients |
|||||||||||
|
|
|
|
Russell
Croman’s StarShrink 0.8 |
shrink
stars |
|||||||||||
|
|
|
|
ProDigital Astronomy Tools
v1.6 |
special
effects |
|||||||||||
|
|
|
|
Annie's
Astro Actions 7.0 |
special
effects |
|||||||||||
|
|
|
|
Neat Image
Pro 8.3.0 |
smooth
image |
|||||||||||
|
|
|
|
Rogelio
Bernal Andreo’s HLVG |
remove
green coloring |
|||||||||||
|
|
|
|
Rogelio
Bernal WhiteCal |
color
balance |
|||||||||||
|
|
|
|
|
||||||||||||
|
Support |
|
Aladin 9.013 |
sky atlas |
||||||||||||
|
Software |
|
Sky
Tools Professional 4.0e |
session
planning |
||||||||||||
|
|
|
CCDNavigator
2.0.78 |
session
planning |
||||||||||||
|
|
|
CCDCalc
1.4.15 |
session
planning |
||||||||||||
|
|
|
PEMPro 3.00.27 |
mount
maintenance |
||||||||||||
|
|
|
SQM
Reader Pro 3.1.1.0 |
Sky
Quality monitor |
||||||||||||
|
|
|
AAG
Cloud Watcher 7.20.100 |
Cloud/Rain
monitor |
||||||||||||
|
|
|
PWRcheck
1.48 |
AP900
power monitoring |
||||||||||||
|
|
|
CCDInspector
2.5.3 |
scope
collimation, CCDStack plugin |
||||||||||||
|
|
|
PixInsight
1.8.5.1353 |
processing |
||||||||||||
|
|
|
FITS4Win2
2.03 |
windows
explorer FITS plugin |
||||||||||||
|
|
|
FireCapture 2.5.03 |
ZWO
and Imaging Source capture |
||||||||||||
|
|
|
usbcam
2.4.14 |
Imaging Source camera driver |
||||||||||||
|
|
|
AutoStakkert 2.6.6 |
video
processing |
||||||||||||
|
|
|
Team
Viewer 13 |
remote control |
||||||||||||
|
|
|
Radmin 3.5 |
remote control |
||||||||||||
|
|
|
|
|
||||||||||||
|
|
|
* AP900 and ST-402 use Switchcraft S760K with center positive
power plug |
|||||||||||||
Note: Like every other
amateur astronomer, I’ve acquired gobs of scopes, cameras, eyepieces, software,
and miscellaneous stuff over many years including 6 scopes, 6 CCD cameras and 4
video cameras. The above list, although intended to be detailed & complete,
only includes the equipment I currently use for imaging.
|
Planewave imaging train : |
|
|
|
|
|
12.5” Planewave scope with Hedrick focuser |
|
|
Planewave AP 2.7” adapter |
|
|
AP 0.6” extension tube |
|
|
Astrodon AP 2.7” to MMOAG adapter (included with MMOAG) |
|
|
Astrodon
MMOAG |
|
|
|
helical focuser
train : |
|
|
1” extension tube |
|
|
SBIG 1¼” to T mount nosepiece |
|
|
SBIG ST-402 camera |
|
Astrodon MMOAG to AP 2.7” adapter (included with MMOAG) |
|
|
AP 1.25” extension tube |
|
|
Precise Parts AP 2.7” to Centerline adapter (length
0.078”) |
|
|
FLI Centerline filter wheel |
|
|
FLI Centerline to Proline flange |
|
|
FLI Proline 16803 camera |
|
|
FSQ 106 imaging train : |
|
|
|
|
|
FSQ 106 EDX III scope with focuser & CAA removed
(extension tube remains on scope) |
|
|
Precise Parts FSQ-106ED/EDX II/III (no focuser) to Tak
Auxiliary Ring M92 (length 3.0”) |
|
|
Precise Parts Tak Auxiliary Ring M92 to AP 2.7”
extension tube (length 0.736”) |
|
|
AP 0.90” extension tube |
|
|
AP 1.75” extension tube |
|
|
FLI AD58 AP 2.7” to Atlas adapter |
|
|
FLI Atlas focuser
(focus point ~63,000 to 70,000 units out of 105,000) |
|
|
FLI AD62 Atlas to Centerline adapter |
|
|
FLI Centerline filter wheel |
|
|
FLI Centerline to Proline flange |
|
|
FLI Proline 16803 camera |
|
